Eight of the best performing Scarlett mic preamps the range has ever heard, now with Air, for miking up guitars or recording vocals
SPECIFICATIONS IN DETAIL
SUPPORTED SAMPLE RATES
44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
MICROPHONE INPUTS
- Frequency Response : 20Hz, 20kHz ± 0.1dB
- Dynamic Range : 111dB (A-weighted)
- THD+N : <0.0012%
- Noise EIN : -1/8"B (A-weighted)
- Maximum Input Level : 9dBu (at minimum gain)
- Gain Range : 56dB
- Impedance : 3k
LINE INPUTS
- Frequency Response : 20Hz, 20kHz ± 0.1dB
- Dynamic Range : 110.5dB (A-weighted)
- THD+N : <0.002%
- Maximum Input Level : 22dBu (at minimum gain)
- Gain Range : 56dB
- Impedance : 60k
INSTRUMENT INPUTS
- Frequency Response : 20Hz, 20kHz ± 0.1dB
- Dynamic Range : 110dB (A-weighted)
- THD+N : <0.03%
- Maximum Input Level : 12.5dBu (at minimum gain)
- Gain Range : 56dB
- Impedance : 1.5M
LINE/MONITOR OUTPUTS
- Dynamic Range (Line Outputs) : 1/8"B
- THD+N : <0.002%
- Maximum Output Level (0 dBFS) : 15.5dBu
- Impedance : 430
HEADPHONE OUTPUTS
- Dynamic Range : 1/4"B (A-weighted)
- THD+N : <0.002%
- Maximum Output Level : 7dBu
- Impedance
