Key Features

• Purposeful Product Design
• JBL Waveguide Technology
• Bluetooth Integration

General Specifications

• System Type:  Self powered 12″, two-way, bass-reflex
• Max SPL Output:  126dB
• Frequency Range (-10dB):  48 Hz – 20 kHz
• Frequency Response (±3 dB):  57 Hz – 20 kHz
• Coverage Pattern:  100° x 60°
• Amplifier Design:  Class D
• Power Rating:  1000W Peak (700W LF + 300W HF), 500W Continuous (350W LF + 150W HF)
• Mic Inputs:  3 Parametric EQs + Hi & Lo Shelf
• Phantom Power:  No
• EQ:  3 Parametric EQs + Hi & Lo Shelf
• Effects: DSP Presets
• Inputs:  2 x Balanced XLR-1/4” combination inputs
• Outputs:  1 x male XLR loop thru out
• Enclosure:  Polypropylene
• Dimensions (WxDxH):  380mm X 316mm X 664mm / 14.96″ X 12.44″ X 26.14″
• Weight:  14.96kgs / 33lbs
