- The advanced DSP has 40 real-time parametric EQs with multiple slopes. There are 100 user presets available for user-friendliness, making it easy to call up presets for the next applications.
- In addition, the amplifier enables networked control via the IntelliDrive Controller. It is a comprehensive control via software that can be downloaded for PC and Mac.
- The built-in IDEEA technology allows additional power savings with the amplifier. The housing consists of an aluminium front and a steel chassis.
- 2 amplifier channels
- Max. Total power of all channels: 1200 W
- Peak output voltage per channel: 50 Vrms
- Max. Output current: 16 arms
- Max output power (all channels controlled)
- 2 Ohm: 500 W
- 4 Ohm: 600 W
- 8 Ohm: 300 W
- 16 Ohm: 150 W
- THD 20 Hz - 20 kHz at 1 W: <0.1%
- THD at 1 kHz and 1 dB under clipping: <0.05%
- Signal-to-noise ratio: > 102 dBA
- Channel separation (crosstalk) at 1 kHz: > 80 dB
- Frequency response: 2 Hz - 42 kHz
- Input impedance: 18 kOhm
- Common mode rejection (CMR): 50 dB
- Output impedance: 25 mOhm
- SCVPL: 70 V peak
- Sensitivity for full power: 6 dBu
- Gain (all DSP controls set to 0 dB): 30.2 dB
- Level adjustment (per channel): Software controlled from -inf to 0 dB
- Analog inputs (per channel) Neutrik XLR, 3pin female
- Analog Input Connector (per channel), Neutrik XLR, 3-pin connector
- AES input jacks (per channel), Neutrik XLR, 3pin female
- AES Input Link Connectors (per channel), Neutrik XLR, 3-pin connector
- Output connections (per channel)
- Neutrik speakON / link
- Buttons: Power, Menu, Back, Mute (per channel), Power
- Encoder: Setting / Adjusting
- Cooling: single fan, front to rear airflow, no filter required, temperature controlled speed
- Nominal voltage: 100 - 240 VAC
- Operating voltage: 60 - 265 V alternating current
- Standby consumption: <6.5 W
- Mains plug: IEC input
- Dimensions (rack rail to rear panel): W: 483 mm (19 "), H: 44 mm (1 U), D: 272 mm (10.7")
- Dimensions (total including handles and rear support): W: 483 mm (19 "), H: 44 mm (1 U), D: 344 mm (13.5")
- Schwarz anodized aluminium front and black / grey steel chassis
