Pioneer XY-3B
Pioneer XY-3B
Regular price
R 122,118.58 ZAR
Regular price
Sale price
R 122,118.58 ZAR
Unit price
/
per
Secure Delivery In All Orders
Secure Checkout & Payments
Low in Stock, Order Soon!
ORDER ON WHATSAPP
Couldn't load pickup availability
Payment methods
In the XY-3B, an 8-inch cone driver delivers clean and precise mid-range frequencies using Pioneer Pro Audio’s X-Phase system. A 1-inch compression driver produces crystal-clear HF which, thanks to the moulded Bi-horn, seamlessly blends with the mids. Two 12-inch drivers create tight, chest-pumping low mid.
| Type | 3WAY Bi-amp loudspeaker |
|---|---|
| Enclosure | 15 mm birch plywood |
| Drivers | LF：12-inch neodymium cone driver x 2 MF：8-inch neodymium cone driver HF：1-inch exit neodymium compression driver |
| Frequency Response | 55 Hz～17 kHz |
| Sensitivity | LF：102 dB MHF：107 dB |
| Power handling | LF：1200 W(RMS), 2400 W(Program) MHF：200 W(RMS), 400 W(Program) |
| Max SPL | LF：133 dB(cont.)、139 dB(peak) MHF：130 dB(cont.)、136 dB(peak) |
| Terminals | speakON® NL4 x 2 |
| Impedance | LF：4Ω MHF：8Ω |
| Dimension (w x h x d) | 530 mm x 1080 mm x 540 mm |
| Weight | 57.6 kg |
