Pioneer XY101

Name: Pioneer XY101
Brand: Pioneer
Price: 30528.58 ZAR
Availability: InStock

R 30,528.58 ZAR

Sale Sold out

Product variants

Quantity

Secure Delivery In All Orders

Secure Checkout & Payments

Low in Stock, Order Soon!

ORDER ON WHATSAPP

Two-way full range speaker with 8-inch LF driver and a 1-inch compression driver.
Passive crossover board features separate cooling zones to ensure safe and continuous operations in the toughest environments.
Wide dispersion of 90 × 60 degrees, with rotatable horn for horizontal installation.
Designed for fixed and mobile applications, with a wide array of flying options.
Features top hats for quick set-up.
NL4 INPUT and LINK OUT connections as standard.
Robust enclosure made from premium multi-laminate birch plywood.
Impact resistant textured paint finish.

Enclosure Type	Two-way passive, reflex-loaded
Frequency Response	70 Hz to 20 kHz
Sensitivity (1 W/1 m)	94 dB
Nominal Impedance	8 Ω
Power Handling	400 W RMS, 800 W Program
Maximum SPL	120 dB cont., 126 dB peak
Dispersion	90 °H × 60 °V, Rotatable
Driver Configuration	10 inch (250 mm) neodymium LF cone driver, 1 inch (25 mm) exit neodymium HF compression driver
Crossover	Asymmetric internal passive crossover
Connectors	2 × Neutrik SpeakON™ NL4
Dimensions (W×H×D)	292 × 508 × 280 mm (11.5 × 20 × 11 inch)
Weight	14 kg (30.9 lbs)
Rigging and Hardware	8 × M8 threaded mounting points (4 top/4 bottom), 3 × M8 threaded mounting points on rear, 4 × M8 threaded mounting points on side (2 left/2 right), 4 × M6 threaded points on rear (for wall mount bracket), 1 × flush handle on rear, 1 × 35 mm polemount socket
Grille	Hex punched steel
Enclosure	15 mm (0.6 inch) birch plywood
Finish	Impact-resistant, Black semi-matt textured
Suggested Power Amplifier	Recommended : K2DSP Minimum : M30DHDSP
Accessories	polemount socket cover (-W model only)
