- True active 250 W class AB design
- 35 Hz – 130 Hz frequency response
- Stereo input board, stereo x-over output
- Selectable low pass filter
- 10" composite fibreglass woofer
- Low distortion reflex port
- Lacquer painted medium density cabinet
SPECIFICATIONS
Transducers
WOOFER:
10''
Input/Output section
INPUT SIGNAL:
bal/unbal
INPUT CONNECTORS:
XLR, Jack, RCA
INPUT SENSITIVITY:
-2 dBu
Processor section
CROSSOVER FREQUENCIES:
50 Hz - 120 Hz
PROTECTIONS:
Thermal, RMS
LIMITER:
Soft Limiter
CONTROLS:
Phase
Power section
TOTAL POWER:
500 W Peak, 250 W RMS
LOW FREQUENCIES:
500 W Peak, 250 W RMS
COOLING:
Convection
CONNECTIONS:
XLR, Jack, RCA
Standard compliance
CE MARKING:
Yes
Physical specifications
CABINET/CASE MATERIAL:
MDF
COLOR:
Black
Size
HEIGHT:
384 mm / 15.12 inches
WIDTH:
356 mm / 14.02 inches
DEPTH:
403 mm / 15.87 inches
WEIGHT:
17.6 kg / 38.8 lbs
Shipping informations
PACKAGE HEIGHT:
384 mm / 15.12 inches
PACKAGE WIDTH:
403 mm / 15.87 inches
PACKAGE DEPTH:
356 mm / 14.02 inches
PACKAGE WEIGHT:
20.5 kg / 45.19 lbs
