SPECIFICATIONS
Acoustical specifications
FREQUENCY RESPONSE:
50 Hz ÷ 20000 Hz
MAX SPL @ 1M:
107 dB
HORIZONTAL COVERAGE ANGLE:
110°
VERTICAL COVERAGE ANGLE:
70°
Transducers
DOME TWEETER:
1.0'' neo, 1.0'' v.c
WOOFER:
5.0''
Input/Output section
INPUT SIGNAL:
bal/unbal
INPUT CONNECTORS:
XLR, Jack, RCA
INPUT SENSITIVITY:
-2 dBu
Processor section
CROSSOVER FREQUENCIES:
2000Hz
LIMITER:
Soft Limiter
Power section
TOTAL POWER:
200 W Peak, 100 W RMS
HIGH FREQUENCIES:
50 W Peak, 25 W RMS
LOW FREQUENCIES:
150 W Peak, 75 W RMS
CONNECTIONS:
XLR, Jack, RCA
Standard compliance
CE MARKING:
Yes
Physical specifications
CABINET/CASE MATERIAL:
MDF
COLOR:
Black - RAL 9005
Size
HEIGHT:
300 mm / 11.81 inches
WIDTH:
185 mm / 7.28 inches
DEPTH:
243 mm / 9.57 inches
WEIGHT:
4.3 kg / 9.48 lbs
Shipping informations
PACKAGE HEIGHT:
400 mm / 15.75 inches
PACKAGE WIDTH:
339 mm / 13.35 inches
PACKAGE DEPTH:
261 mm / 10.28 inches
PACKAGE WEIGHT:
6 kg / 13.23 lbs
